General Grabber HTS tire model comes in 69 tire sizes with maximum tire load capacity range of 1709 to 3750 pounds and maximum tire inflation range of 44 to 80 psi. Select General Grabber HTS tire size to find its maximum tire load capacity at its specified tire inflation. These values may vary based on tire load range or ply rating. Check General Grabber HTS tire sidewall for more information. Remember that psi value printed on the tire sidewall is the maximum tire pressure that General Grabber HTS tire can be inflated to at its corresponding maximum weight capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate General Grabber HTS tires beyond the maximum tire load capacity and maximum tire inflation values indicated on tire sidewall.
Check General tire pressure charts for other General tire models.
General Grabber HTS Tire Pressure Chart
Tire Size | Tire Size Type | Load Index | Dual Load Index | Speed Rating | Load Range | Maximum Load | Maximum Dual Load | Maximum Tire Pressure | ||
---|---|---|---|---|---|---|---|---|---|---|
215/70R16 |
Metric | 100 | S | SL | 1764 lbs | 44 psi | Show Specs | |||
225/65R17 |
Metric | 102 | T | SL | 1874 lbs | 44 psi | Show Specs | |||
225/70R15 |
Metric | 100 | T | SL | 1764 lbs | 44 psi | Show Specs | |||
225/70R16 |
Metric | 103 | S | SL | 1929 lbs | 44 psi | Show Specs | |||
225/75R16 |
Metric | 104 | S | SL | 1984 lbs | 44 psi | Show Specs | |||
235/60R18 |
Metric | 107 | H | XL | 2149 lbs | 50 psi | Show Specs | |||
235/65R16 |
Metric | 103 | T | SL | 1929 lbs | 44 psi | Show Specs | |||
235/65R17 |
Metric | 108 | T | XL | 2205 lbs | 51 psi | Show Specs | |||
235/65R17 |
Metric | 108 | H | XL | 2205 lbs | 51 psi | Show Specs | |||
235/65R18 |
Metric | 106 | S | SL | 2095 lbs | 44 psi | Show Specs | |||
235/70R15 |
Metric | 103 | T | SL | 1929 lbs | 44 psi | Show Specs | |||
235/70R16 |
Metric | 106 | T | SL | 2094 lbs | 44 psi | Show Specs | |||
235/70R17 |
Metric | 111 | T | XL | 2403 lbs | 51 psi | Show Specs | |||
235/75R15 |
Metric | 105 | T | SL | 2039 lbs | 44 psi | Show Specs | |||
235/75R15 |
Metric | 109 | T | XL | 2271 lbs | 51 psi | Show Specs | |||
235/75R16 |
Metric | 108 | S | SL | 2205 lbs | 44 psi | Show Specs | |||
235/75R17 |
Metric | 109 | S | SL | 2271 lbs | 44 psi | Show Specs | |||
245/55R19 |
Metric | 103 | T | SL | 1929 lbs | 44 psi | Show Specs | |||
245/60R18 |
Metric | 105 | H | SL | 2039 lbs | 51 psi | Show Specs | |||
245/65R17 |
Metric | 111 | T | XL | 2403 lbs | 51 psi | Show Specs | |||
245/70R16 |
Metric | 107 | S | SL | 2150 lbs | 44 psi | Show Specs | |||
245/70R17 |
Metric | 110 | S | SL | 2337 lbs | 44 psi | Show Specs | |||
245/75R16 |
Metric | 111 | S | SL | 2403 lbs | 44 psi | Show Specs | |||
255/55R18 |
Metric | 109 | H | XL | 2271 lbs | 51 psi | Show Specs | |||
255/55R20 |
Metric | 107 | H | SL | 2149 lbs | 51 psi | Show Specs | |||
255/60R19 |
Metric | 109 | S | SL | 2271 lbs | 44 psi | Show Specs | |||
255/65R16 |
Metric | 109 | S | SL | 2271 lbs | 44 psi | Show Specs | |||
255/65R16 |
Metric | 109 | H | SL | 2271 lbs | 51 psi | Show Specs | |||
255/65R17 |
Metric | 110 | S | SL | 2337 lbs | 44 psi | Show Specs | |||
255/65R18 |
Metric | 111 | S | SL | 2403 lbs | 44 psi | Show Specs | |||
255/70R15 |
Metric | 108 | S | SL | 2205 lbs | 44 psi | Show Specs | |||
255/70R16 |
Metric | 111 | S | SL | 2403 lbs | 44 psi | Show Specs | |||
255/70R18 |
Metric | 113 | T | SL | 2535 lbs | 44 psi | Show Specs | |||
265/50R20 |
Metric | 107 | T | SL | 2149 lbs | 44 psi | Show Specs | |||
265/60R18 |
Metric | 110 | T | SL | 2337 lbs | 44 psi | Show Specs | |||
265/65R17 |
Metric | 112 | T | SL | 2469 lbs | 44 psi | Show Specs | |||
265/65R18 |
Metric | 114 | T | SL | 2601 lbs | 44 psi | Show Specs | |||
265/70R15 |
Metric | 112 | S | SL | 2469 lbs | 44 psi | Show Specs | |||
265/70R16 |
Metric | 112 | S | SL | 2469 lbs | 44 psi | Show Specs | |||
265/70R18 |
Metric | 116 | S | SL | 2756 lbs | 44 psi | Show Specs | |||
265/75R15 |
Metric | 112 | S | SL | 2469 lbs | 44 psi | Show Specs | |||
265/75R16 |
Metric | 116 | T | SL | 2756 lbs | 44 psi | Show Specs | |||
275/55R17 |
Metric | 109 | V | SL | 2271 lbs | 51 psi | Show Specs | |||
275/55R20 |
Metric | 117 | S | XL | 2833 lbs | 51 psi | Show Specs | |||
275/60R17 |
Metric | 110 | S | SL | 2337 lbs | 44 psi | Show Specs | |||
275/60R18 |
Metric | 113 | H | SL | 2535 lbs | 51 psi | Show Specs | |||
275/60R20 |
Metric | 119 | S | XL | 2998 lbs | 51 psi | Show Specs | |||
275/70R16 |
Metric | 114 | S | SL | 2601 lbs | 44 psi | Show Specs | |||
285/45R22 |
Metric | 114 | H | XL | 2601 lbs | 51 psi | Show Specs | |||
LT225/75R16 |
LT-Metric | 115 | 112 | S | E | 2680 lbs | 2470 lbs | 80 psi | Show Specs | |
LT235/75R15 |
LT-Metric | 104 | 101 | Q | C | 1985 lbs | 1820 lbs | 50 psi | Show Specs | |
LT235/80R17 |
LT-Metric | 120 | 117 | R | E | 3085 lbs | 80 psi | Show Specs | ||
LT235/85R16 |
LT-Metric | 120 | 116 | Q | E | 3042 lbs | 2755 lbs | 80 psi | Show Specs | |
LT245/70R17 |
LT-Metric | 119 | 116 | S | E | 3000 lbs | 2755 lbs | 80 psi | Show Specs | |
LT245/75R16 |
LT-Metric | 120 | 116 | S | E | 3042 lbs | 2755 lbs | 80 psi | Show Specs | |
LT245/75R17 |
LT-Metric | 121 | 118 | S | E | 3195 lbs | 2910 lbs | 80 psi | Show Specs | |
LT265/60R20 |
LT-Metric | 121 | 118 | R | E | 3195 lbs | 2910 lbs | 80 psi | Show Specs | |
LT265/70R17 |
LT-Metric | 121 | 118 | S | E | 3195 lbs | 2910 lbs | 80 psi | Show Specs | |
LT265/75R16 |
LT-Metric | 123 | 120 | Q | E | 3415 lbs | 3085 lbs | 80 psi | Show Specs | |
LT275/65R18 |
LT-Metric | 123 | 120 | S | E | 3415 lbs | 3085 lbs | 80 psi | Show Specs | |
LT275/65R20 |
LT-Metric | 126 | 123 | S | E | 3750 lbs | 3415 lbs | 80 psi | Show Specs | |
LT275/70R18 |
LT-Metric | 125 | 122 | S | E | 3640 lbs | 3305 lbs | 80 psi | Show Specs | |
LT285/70R17 |
LT-Metric | 121 | 118 | Q | D | 3195 lbs | 2910 lbs | 65 psi | Show Specs | |
LT315/70R17 |
LT-Metric | 121 | 118 | S | D | 3195 lbs | 2910 lbs | 50 psi | Show Specs | |
P215/70R16 |
P-Metric | 99 | S | SL | 1709 lbs | 44 psi | Show Specs | |||
P245/70R17 |
P-Metric | 108 | S | SL | 2205 lbs | 44 psi | Show Specs | |||
P245/70R17 |
P-Metric | 108 | T | SL | 2205 lbs | 44 psi | Show Specs | |||
P255/70R17 |
P-Metric | 110 | S | SL | 2337 lbs | 44 psi | Show Specs | |||
P265/70R17 |
P-Metric | 113 | S | SL | 2535 lbs | 44 psi | Show Specs |
