General Grabber HD Tire Pressure Chart

General tire pressure charts. General Grabber HD tire pressure chart with maximum tire load capacity and tire inflation for every General Grabber HD tire size.

No Image Available

General Grabber HD tire model comes in 11 tire sizes. Check General Grabber HD tire pressure chart to find maximum tire load capacity and its specified tire inflation based on your General Grabber HD tire size. Remember that tire pressure psi value printed on General Grabber HD tire sidewall is its maximum tire pressure that General Grabber HD tire can be inflated to at its corresponding maximum weight capacity, and not a recommended tire pressure setting for your vehicle.

Keep in mind that General Grabber HD tires can naturally lose 1 to 2 psi of air pressure monthly, so check your General Grabber HD tire pressure regularly to keep tires properly inflated.

Tire pressure is also affected by changes in outside temperature. As a rule, tire pressure for General Grabber HD tires will drop by about 1 psi for every 10 degrees Fahrenheit drop in atmospheric temperature. Maintain proper General Grabber HD winter tire pressure by compensating air pressure to your vehicle's recommended tire pressure levels.

General Grabber HD Tire Pressure Chart

Tire Size Tire Size Type Load Index Dual Load Index Speed Rating Load Range Maximum Load Maximum Dual Load Maximum Tire Pressure
195/70R15
104R D
Metric 104 102 R D 1985 lbs 1875 lbs 75 psi Show Specs
235/65R16
121R E
Metric 121 119 R E 3195 lbs 3000 lbs 90 psi Show Specs
LT215/85R16
115R E
LT-Metric 115 112 R E 2680 lbs 2470 lbs 80 psi Show Specs
LT225/75R16
115R E
LT-Metric 115 112 R E 2680 lbs 2470 lbs 80 psi Show Specs
LT225/75R16
121R E
LT-Metric 121 120 R E 3195 lbs 90 psi Show Specs
LT235/85R16
120R E
LT-Metric 120 116 R E 3042 lbs 2756 lbs 80 psi Show Specs
LT245/70R17
119R E
LT-Metric 119 116 R E 3000 lbs 2756 lbs 80 psi Show Specs
LT245/75R16
120S E
LT-Metric 120 116 S E 3042 lbs 2756 lbs 80 psi Show Specs
LT245/75R17
121S E
LT-Metric 121 118 S E 3195 lbs 2910 lbs 80 psi Show Specs
LT265/70R17
121R E
LT-Metric 121 118 R E 3195 lbs 2910 lbs 80 psi Show Specs
LT265/75R16
123R E
LT-Metric 123 120 R E 3415 lbs 3085 lbs 80 psi Show Specs
