General Grabber HTS 60 Tire Pressure Chart

General Grabber HTS 60
Amazon eBay TireRack

General Grabber HTS 60 tires come in 59 tire sizes with maximum tire load capacity of 1764 pounds to 3638/3307 pounds and maximum tire inflation of 44 psi to 80 psi.

General Grabber HTS 60 tire load capacity and tire inflation settings may vary based on tire load index / load range. Check General Grabber HTS 60 tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure General Grabber HTS 60 tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate General Grabber HTS 60 tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.

Select General Grabber HTS 60 tire size for its maximum tire inflation and load capacity.

Tire Size Max Load Capacity
(single / dual rear wheels)
Maximum Tire Pressure

215/70R16 100T

1764 lbs 44 psi

225/70R16 103T

1929 lbs 44 psi

225/75R16 104S

1984 lbs 44 psi

235/55R19 101H

1819 lbs 51 psi

235/55R20 102H

1874 lbs 51 psi

235/60R18 103H

1929 lbs 51 psi

235/65R17 108H

2205 lbs 51 psi

235/65R18 106T

2094 lbs 44 psi

235/70R16 106T

2094 lbs 44 psi

235/70R17 111T

2403 lbs 51 psi

235/75R16 108S

2205 lbs 44 psi

245/50R20 102H

1874 lbs 51 psi

245/55R19 103T

1929 lbs 44 psi

245/60R18 105H

2039 lbs 51 psi

245/60R20 107H

2149 lbs 51 psi

245/65R17 107T

2149 lbs 44 psi

245/70R16 107T

2149 lbs 44 psi

245/70R17 110T

2337 lbs 44 psi

245/75R16 111S

2403 lbs 44 psi

255/50R19 107H

2149 lbs 51 psi

255/50R20 109H

2271 lbs 51 psi

255/55R18 109H

2271 lbs 51 psi

255/55R20 107H

2149 lbs 51 psi

255/60R19 109H

2271 lbs 51 psi

255/65R16 109H

2271 lbs 51 psi

255/65R17 110T

2337 lbs 44 psi

255/65R18 111S

2403 lbs 44 psi

255/70R15 108S

2205 lbs 44 psi

255/70R16 111S

2403 lbs 44 psi

255/70R18 113T

2535 lbs 44 psi

265/50R20 107T

2149 lbs 44 psi

265/60R18 110T

2337 lbs 44 psi

265/65R17 112T

2469 lbs 44 psi

265/65R18 114T

2601 lbs 44 psi

265/70R16 112T

2469 lbs 44 psi

265/70R17 115S

2679 lbs 44 psi

265/70R18 116T

2756 lbs 44 psi

265/75R15 112S

2469 lbs 44 psi

265/75R16 116T

2756 lbs 44 psi

275/55R20 117H

2833 lbs 51 psi

275/60R17 110T

2337 lbs 44 psi

275/60R20 119T

2998 lbs 51 psi

275/65R18 116T

2756 lbs 44 psi

285/45R22 114H

2601 lbs 51 psi

31x10.50R15 109R

2271 lbs 50 psi

LT235/80R17 120/117R

3086/2833 lbs 80 psi

LT235/85R16 120/116R

3086/2756 lbs 80 psi

LT245/70R17 119/116S

2998/2756 lbs 80 psi

LT245/75R16 120/116S

3086/2756 lbs 80 psi

LT245/75R17 121/118S

3197/2910 lbs 80 psi

LT265/70R17 121/118S

3197/2910 lbs 80 psi

LT265/75R16 123/120R

3417/3086 lbs 80 psi

LT275/65R18 123/120S

3417/3086 lbs 80 psi

LT275/70R18 125/122S

3638/3307 lbs 80 psi

All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
