General Grabber UHP Tire Pressure Chart

General tire pressure charts. General Grabber UHP tire pressure chart with maximum tire load capacity and tire inflation for every General Grabber UHP tire size.

No Image Available

General Grabber UHP tire model comes in 21 tire sizes. Check General Grabber UHP tire pressure chart to find maximum tire load capacity and its specified tire inflation based on your General Grabber UHP tire size. Remember that tire pressure psi value printed on General Grabber UHP tire sidewall is its maximum tire pressure that General Grabber UHP tire can be inflated to at its corresponding maximum weight capacity, and not a recommended tire pressure setting for your vehicle.

Keep in mind that General Grabber UHP tires can naturally lose 1 to 2 psi of air pressure monthly, so check your General Grabber UHP tire pressure regularly to keep tires properly inflated.

Tire pressure is also affected by changes in outside temperature. As a rule, tire pressure for General Grabber UHP tires will drop by about 1 psi for every 10 degrees Fahrenheit drop in atmospheric temperature. Maintain proper General Grabber UHP winter tire pressure by compensating air pressure to your vehicle's recommended tire pressure levels.

General Grabber UHP Tire Pressure Chart

Tire Size Tire Size Type Load Index Dual Load Index Speed Rating Load Range Maximum Load Maximum Dual Load Maximum Tire Pressure
225/55R17
97V SL
Metric 97 V SL 1609 lbs 51 psi Show Specs
235/60R18
107V XL
Metric 107 V XL 2150 lbs 51 psi Show Specs
235/65R17
108T XL
Metric 108 T XL 2205 lbs 50 psi Show Specs
255/45R20
105V XL
Metric 105 V XL 2039 lbs 51 psi Show Specs
255/50R19
107W XL
Metric 107 W XL 2150 lbs 51 psi Show Specs
255/55R19
111V XL
Metric 111 V XL 2403 lbs 51 psi Show Specs
255/55ZR18
109W XL
Metric 109 W XL 2271 lbs 51 psi Show Specs
255/60R17
106V SL
Metric 106 V SL 2094 lbs 51 psi Show Specs
255/65R16
109H SL
Metric 109 H SL 2271 lbs 51 psi Show Specs
275/45R20
110V XL
Metric 110 V XL 2337 lbs 51 psi Show Specs
275/55R17
109V SL
Metric 109 V SL 2271 lbs 51 psi Show Specs
275/55R20
117V XL
Metric 117 V XL 2833 lbs 51 psi Show Specs
275/70R16
114T SL
Metric 114 T SL 2601 lbs 44 psi Show Specs
285/50R20
112V SL
Metric 112 V SL 2469 lbs 51 psi Show Specs
295/45R20
114V XL
Metric 114 V XL 2601 lbs 51 psi Show Specs
295/50R20
118V XL
Metric 118 V XL 2910 lbs 51 psi Show Specs
305/35R24
112V XL
Metric 112 V XL 2469 lbs 51 psi Show Specs
305/40R22
114V XL
Metric 114 V XL 2601 lbs 51 psi Show Specs
305/40R23
115V XL
Metric 115 V XL 2679 lbs 51 psi Show Specs
305/45R22
118V XL
Metric 118 V XL 2910 lbs 51 psi Show Specs
315/35R24
114V XL
Metric 114 V XL 2602 lbs 50 psi Show Specs
