Nexen NFera SU1 Tire Pressure Chart
Nexen NFera SU1 tires come in 61 tire sizes with maximum tire load capacity of 1102 pounds to 963 pounds and maximum tire inflation of 44 psi to 51 psi.
Nexen NFera SU1 tire load capacity and tire inflation settings may vary based on tire load index / load range. Check Nexen NFera SU1 tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure Nexen NFera SU1 tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Nexen NFera SU1 tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.
| Best Prices on Nexen NFera SU1 Tires | |
|---|---|
 |
|
 |
|
 from $103 |
|
 from $100 |
|
Select Nexen NFera SU1 tire size for its maximum tire inflation and load capacity.
| Tire Size | Max Load Capacity (single / dual rear wheels) |
Maximum Tire Pressure |
|---|---|---|
|
195/45R15 78W |
937 lbs | 44 psi |
|
195/45R16 84W |
1102 lbs | 50 psi |
|
205/40R16 79W |
963 lbs | 51 psi |
|
205/40R17 84W |
1102 lbs | 50 psi |
|
205/45R16 87W |
1201 lbs | 50 psi |
|
205/50R17 93W |
1433 lbs | 50 psi |
|
215/35R18 84Y |
1102 lbs | 50 psi |
|
215/40R17 87W |
1201 lbs | 50 psi |
|
215/40R18 89Y |
1279 lbs | 50 psi |
|
215/45R17 91W |
1356 lbs | 50 psi |
|
215/55R16 97W |
1609 lbs | 50 psi |
|
225/30R20 85Y |
1135 lbs | 50 psi |
|
225/35R19 88Y |
1235 lbs | 50 psi |
|
225/35R20 90Y |
1323 lbs | 50 psi |
|
225/40R18 92Y |
1389 lbs | 50 psi |
|
225/40R19 93Y |
1433 lbs | 50 psi |
|
225/45R17 94Y |
1477 lbs | 50 psi |
|
225/45R18 95Y |
1521 lbs | 50 psi |
|
225/45R19 96W |
1565 lbs | 50 psi |
|
225/50R16 96W |
1565 lbs | 50 psi |
|
235/30R20 88Y |
1235 lbs | 50 psi |
|
235/30R22 90Y |
1323 lbs | 50 psi |
|
235/35R19 91Y |
1356 lbs | 50 psi |
|
235/40R18 95Y |
1521 lbs | 50 psi |
|
235/45R17 97W |
1609 lbs | 50 psi |
|
245/30R20 90Y |
1323 lbs | 50 psi |
|
245/30R22 92Y |
1389 lbs | 50 psi |
|
245/35R18 92Y |
1389 lbs | 50 psi |
|
245/35R19 93Y |
1433 lbs | 50 psi |
|
245/35R20 95Y |
1521 lbs | 50 psi |
|
245/40R17 95W |
1521 lbs | 50 psi |
|
245/40R18 97Y |
1609 lbs | 50 psi |
|
245/40R19 98Y |
1653 lbs | 50 psi |
|
245/40R20 99Y |
1709 lbs | 50 psi |
|
245/45R18 100Y |
1764 lbs | 50 psi |
|
245/45R19 102Y |
1874 lbs | 50 psi |
|
245/45R20 103Y |
1929 lbs | 50 psi |
|
255/30R19 91Y |
1356 lbs | 50 psi |
|
255/30R24 97Y |
1609 lbs | 50 psi |
|
255/35R18 94Y |
1477 lbs | 50 psi |
|
255/35R19 96W |
1565 lbs | 50 psi |
|
255/35R20 97Y |
1609 lbs | 50 psi |
|
255/40R17 94W |
1477 lbs | 51 psi |
|
255/40R18 99Y |
1709 lbs | 50 psi |
|
255/40R19 100Y |
1764 lbs | 50 psi |
|
255/45R18 103Y |
1929 lbs | 50 psi |
|
255/45R19 104Y |
1984 lbs | 50 psi |
|
265/30R19 93Y |
1433 lbs | 50 psi |
|
265/30R22 97Y |
1609 lbs | 50 psi |
|
265/35R18 97Y |
1609 lbs | 50 psi |
|
275/25R24 96Y |
1565 lbs | 50 psi |
|
275/30R19 96Y |
1565 lbs | 50 psi |
|
275/30R20 97Y |
1609 lbs | 50 psi |
|
275/30R24 101Y |
1819 lbs | 50 psi |
|
275/35R18 99W |
1709 lbs | 50 psi |
|
275/35R19 100Y |
1764 lbs | 50 psi |
|
275/35R20 102Y |
1874 lbs | 50 psi |
|
275/40R17 98W |
1653 lbs | 51 psi |
|
275/40R19 105Y |
2039 lbs | 50 psi |
|
285/30R20 99Y |
1709 lbs | 50 psi |
|
295/25R22 97Y |
1609 lbs | 50 psi |
All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
