Nexen NFera SUR4G Tire Pressure Chart

No Tire Image

Nexen NFera SUR4G tires come in 21 tire sizes with maximum tire load capacity of 1201 pounds to 1874 pounds and maximum tire inflation of 51 psi.

Nexen NFera SUR4G tire load capacity and tire inflation settings may vary based on tire load index / load range. Check Nexen NFera SUR4G tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure Nexen NFera SUR4G tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Nexen NFera SUR4G tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.

Select Nexen NFera SUR4G tire size for its maximum tire inflation and load capacity.

Tire Size Max Load Capacity
(single / dual rear wheels)
Maximum Tire Pressure

205/55R16 91W

1356 lbs 51 psi

215/45R17 87Y

1201 lbs 51 psi

225/40R18 88Y

1235 lbs 51 psi

225/40R19 89Y

1279 lbs 51 psi

225/45R15 87W

1201 lbs 51 psi

225/45R17 91Y

1356 lbs 51 psi

225/45R18 91Y

1356 lbs 51 psi

225/50R16 92W

1389 lbs 51 psi

235/35R19 87Y

1201 lbs 51 psi

235/40R18 91Y

1356 lbs 51 psi

235/45R17 94Y

1477 lbs 51 psi

245/40R17 91Y

1356 lbs 51 psi

245/40R18 93Y

1433 lbs 51 psi

245/40R19 94Y

1477 lbs 51 psi

255/35R18 90Y

1323 lbs 51 psi

255/40R17 94Y

1477 lbs 51 psi

265/35R18 93Y

1433 lbs 51 psi

275/35R18 95Y

1521 lbs 51 psi

275/35R19 96Y

1565 lbs 51 psi

275/40R18 99Y

1709 lbs 51 psi

275/40R20 102W

1874 lbs 51 psi

All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
