Nitto Exo Grappler AWT Tire Pressure Chart

Nitto Exo Grappler AWT
Amazon eBay TireRack

Nitto Exo Grappler AWT tires come in 24 tire sizes with maximum tire load capacity of 3086 pounds to 3858/3527 pounds and maximum tire inflation of 65 psi to 80 psi.

Nitto Exo Grappler AWT tire load capacity and tire inflation settings may vary based on tire load index / load range. Check Nitto Exo Grappler AWT tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure Nitto Exo Grappler AWT tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Nitto Exo Grappler AWT tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.

Select Nitto Exo Grappler AWT tire size for its maximum tire inflation and load capacity.

Tire Size Max Load Capacity
(single / dual rear wheels)
Maximum Tire Pressure

35x11.50R20 124Q

3527 lbs 80 psi

35x12.50R17 121Q

3197 lbs 65 psi

35x12.50R18 123Q

3417 lbs 65 psi

35x12.50R20 121Q

3197 lbs 65 psi

37x13.50R17 121Q

3197 lbs 65 psi

37x13.50R20 127Q

3858 lbs 65 psi

LT235/80R17 120Q

3086 lbs 80 psi

LT245/75R17 121Q

3197 lbs 80 psi

LT265/65R18 122/119Q

3307/2998 lbs 80 psi

LT265/70R17 121Q

3197 lbs 80 psi

LT275/55R20 120/117Q

3086/2833 lbs 80 psi

LT275/60R20 123/120Q

3417/3086 lbs 80 psi

LT275/65R18 123Q

3417 lbs 80 psi

LT275/65R20 126Q

3748 lbs 80 psi

LT275/70R18 125Q

3638 lbs 80 psi

LT285/55R20 122/119Q

3307/2998 lbs 80 psi

LT285/60R20 125/122Q

3638/3307 lbs 80 psi

LT285/65R18 125/122Q

3638/3307 lbs 80 psi

LT285/65R20 127/124Q

3858/3527 lbs 80 psi

LT285/70R17 121Q

3197 lbs 80 psi

LT285/70R18 127/124Q

3858/3527 lbs 80 psi

LT295/55R20 123/120Q

3417/3086 lbs 80 psi

LT305/55R20 121Q

3197 lbs 65 psi

LT325/60R20 126/123Q

3748/3417 lbs 65 psi

All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
