Maxxis Bravo HP-M3 Tire Pressure Chart

Maxxis Bravo HP-M3

Maxxis Bravo HP-M3 tires come in 83 tire sizes with maximum tire load capacity of 1201 pounds to 2679 pounds and maximum tire inflation of 44 psi to 51 psi.

Maxxis Bravo HP-M3 tire load capacity and tire inflation settings may vary based on tire load index / load range. Check Maxxis Bravo HP-M3 tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure Maxxis Bravo HP-M3 tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Maxxis Bravo HP-M3 tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.

Select Maxxis Bravo HP-M3 tire size for its maximum tire inflation and load capacity.

Tire Size Max Load Capacity
(single / dual rear wheels)
Maximum Tire Pressure

195/55R16 87V

1201 lbs 44 psi

205/45R17 88V

1235 lbs 50 psi

205/50R16 87V

1201 lbs 44 psi

205/50R17 93V

1433 lbs 50 psi

205/55R16 91V

1356 lbs 44 psi

205/60R16 92V

1389 lbs 44 psi

205/65R16 95H

1521 lbs 44 psi

205/70R16 97H

1609 lbs 44 psi

215/45R17 91V

1356 lbs 50 psi

215/45R18 93W

1433 lbs 50 psi

215/50R17 95V

1521 lbs 50 psi

215/55R16 93V

1433 lbs 44 psi

215/55R17 94V

1477 lbs 44 psi

215/55R18 99V

1709 lbs 50 psi

215/60R16 95V

1521 lbs 44 psi

215/60R17 100V

1764 lbs 50 psi

215/65R16 98V

1653 lbs 44 psi

215/65R17 99V

1709 lbs 44 psi

215/70R16 104H

1984 lbs 50 psi

225/40R18 92W

1389 lbs 50 psi

225/40R19 93W

1433 lbs 50 psi

225/45R17 91V

1356 lbs 44 psi

225/45R18 95W

1521 lbs 50 psi

225/45R19 96W

1565 lbs 50 psi

225/50R16 92V

1389 lbs 44 psi

225/50R17 94V

1477 lbs 44 psi

225/50R18 99W

1709 lbs 50 psi

225/55R16 95V

1521 lbs 44 psi

225/55R17 97V

1609 lbs 44 psi

225/55R18 98V

1653 lbs 44 psi

225/55R19 99V

1709 lbs 44 psi

225/60R16 98V

1653 lbs 44 psi

225/60R17 99H

1709 lbs 44 psi

225/60R18 100W

1764 lbs 51 psi

225/65R16 100V

1764 lbs 44 psi

225/65R17 106V

2094 lbs 50 psi

225/70R16 107H

2149 lbs 50 psi

235/40R18 95W

1521 lbs 50 psi

235/40R19 96W

1565 lbs 50 psi

235/45R17 94W

1477 lbs 51 psi

235/45R18 94W

1477 lbs 51 psi

235/50R17 100V

1764 lbs 50 psi

235/50R18 101W

1819 lbs 50 psi

235/55R17 103V

1929 lbs 50 psi

235/55R18 100V

1764 lbs 44 psi

235/55R19 101V

1819 lbs 44 psi

235/55R20 105V

2039 lbs 50 psi

235/60R16 100V

1764 lbs 44 psi

235/60R17 106V

2094 lbs 50 psi

235/60R18 107V

2149 lbs 50 psi

235/65R16 103V

1929 lbs 44 psi

235/65R17 108V

2205 lbs 50 psi

235/65R18 110V

2337 lbs 50 psi

235/70R16 109H

2271 lbs 50 psi

245/40R17 95V

1521 lbs 50 psi

245/40R18 97W

1609 lbs 50 psi

245/40R19 98W

1653 lbs 50 psi

245/40R20 99W

1709 lbs 50 psi

245/45R17 99V

1709 lbs 50 psi

245/45R18 100V

1764 lbs 50 psi

245/45R19 98W

1653 lbs 51 psi

245/45R20 99W

1709 lbs 51 psi

245/50R20 102V

1874 lbs 44 psi

245/55R18 103W

1929 lbs 51 psi

245/55R19 103V

1929 lbs 44 psi

245/60R18 105V

2039 lbs 44 psi

245/65R17 111V

2403 lbs 50 psi

245/70R17 114H

2601 lbs 50 psi

255/40R18 99W

1709 lbs 50 psi

255/40R19 100W

1764 lbs 50 psi

255/45R18 103W

1929 lbs 50 psi

255/45R19 104W

1984 lbs 50 psi

255/45R20 105W

2039 lbs 50 psi

255/50R19 107V

2149 lbs 50 psi

255/50R20 109V

2271 lbs 50 psi

255/55R18 109V

2271 lbs 50 psi

255/55R20 110V

2337 lbs 50 psi

255/60R19 113V

2535 lbs 50 psi

255/65R18 115V

2679 lbs 50 psi

265/50R20 111V

2403 lbs 50 psi

265/60R18 114V

2601 lbs 50 psi

275/40R20 106W

2094 lbs 50 psi

All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
