Maxxis Bravo AT-771 Tire Pressure Chart

Maxxis Bravo AT-771

Maxxis Bravo AT-771 tires come in 53 tire sizes with maximum tire load capacity of 1609 pounds to 3748/3417 pounds and maximum tire inflation of 44 psi to 80 psi.

Maxxis Bravo AT-771 tire load capacity and tire inflation settings may vary based on tire load index / load range. Check Maxxis Bravo AT-771 tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure Maxxis Bravo AT-771 tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Maxxis Bravo AT-771 tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.

Select Maxxis Bravo AT-771 tire size for its maximum tire inflation and load capacity.

Tire Size Max Load Capacity
(single / dual rear wheels)
Maximum Tire Pressure

205/75R15 97T

1609 lbs 44 psi

215/70R16 100T

1764 lbs 44 psi

225/65R17 102T

1874 lbs 44 psi

235/60R16 104H

1984 lbs 50 psi

235/65R17 104T

1984 lbs 44 psi

235/70R16 106T

2094 lbs 44 psi

235/75R15 109S

2271 lbs 50 psi

245/65R17 107S

2149 lbs 44 psi

245/70R16 107T

2149 lbs 44 psi

245/70R17 110S

2337 lbs 44 psi

255/55R18 109H

2271 lbs 50 psi

255/60R18 112H

2469 lbs 50 psi

255/65R16 109T

2271 lbs 44 psi

255/65R17 110H

2337 lbs 44 psi

255/70R15 108T

2205 lbs 44 psi

255/70R16 111T

2403 lbs 44 psi

255/70R17 112S

2469 lbs 44 psi

265/65R17 112T

2469 lbs 44 psi

265/70R16 112T

2469 lbs 44 psi

265/70R17 115S

2679 lbs 44 psi

265/75R16 116T

2756 lbs 44 psi

275/55R20 117T

2833 lbs 50 psi

275/60R20 115S

2679 lbs 44 psi

275/65R17 115T

2679 lbs 44 psi

275/65R18 116S

2756 lbs 44 psi

305/50R20 120T

3086 lbs 50 psi

30x9.50R15 104S

1984 lbs 50 psi

31x10.50R15 109S

2271 lbs 50 psi

33x12.50R15 108S

2205 lbs 50 psi

LT225/70R16 102/99S

1874/1709 lbs 50 psi

LT225/75R16 115/112Q

2679/2469 lbs 80 psi

LT235/75R15 104/101S

1984/1819 lbs 50 psi

LT235/80R17 120/117R

3086/2833 lbs 80 psi

LT235/85R16 120/116S

3086/2756 lbs 80 psi

LT245/75R16 120/116Q

3086/2756 lbs 80 psi

LT245/75R17 121/118S

3197/2910 lbs 80 psi

LT265/70R16 117/114S

2833/2601 lbs 65 psi

LT265/70R17 121/118R

3197/2910 lbs 80 psi

LT265/75R16 119/116Q

2998/2756 lbs 65 psi

LT275/65R18 123/120S

3417/3086 lbs 80 psi

LT275/70R18 125/122R

3638/3307 lbs 80 psi

LT285/65R18 125/122R

3638/3307 lbs 80 psi

LT285/70R17 121/118R

3197/2910 lbs 65 psi

LT285/75R16 122/119R

3307/2998 lbs 65 psi

LT305/55R20 121/118S

3197/2910 lbs 65 psi

LT305/70R17 119/116Q

2998/2756 lbs 65 psi

LT315/70R17 121/118R

3197/2910 lbs 65 psi

LT325/60R20 126/123S

3748/3417 lbs 65 psi

LT325/65R18 121/118S

3197/2910 lbs 50 psi

All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
