Select Sumitomo HTR Z5 tire size to find its maximum tire load capacity at its specified tire inflation. Tire load capacity and tire inflation settings may vary based on tire load range or ply rating. Check Sumitomo HTR Z5 tire sidewall for more information. Remember that psi value printed on the tire sidewall is the maximum tire pressure that Sumitomo HTR Z5 tire can be inflated to at its corresponding maximum weight capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Sumitomo HTR Z5 tires beyond the maximum tire load capacity and maximum tire inflation values indicated on the tire sidewall.

Check Sumitomo tire pressure charts for other Sumitomo tire models.

#### Sumitomo HTR Z5 Tire Pressure Chart

Tire Size | Tire Size Type | Tire Load Index | Tire Speed Rating | Maximum Tire Load | Maximum Dual Tire Load | Maximum Tire Inflation | ||
---|---|---|---|---|---|---|---|---|

205/50R17 |
Metric | 93 | Y | 1433 lbs | 50 psi | Show Specs | ||

215/40R18 |
Metric | 89 | Y | 1279 lbs | 50 psi | Show Specs | ||

215/45R17 |
Metric | 91 | Y | 1356 lbs | 50 psi | Show Specs | ||

225/35R19 |
Metric | 88 | Y | 1235 lbs | 50 psi | Show Specs | ||

225/35R20 |
Metric | 90 | Y | 1323 lbs | 50 psi | Show Specs | ||

225/40R18 |
Metric | 92 | Y | 1389 lbs | 50 psi | Show Specs | ||

225/45R17 |
Metric | 94 | Y | 1478 lbs | 50 psi | Show Specs | ||

225/45R18 |
Metric | 95 | Y | 1522 lbs | 50 psi | Show Specs | ||

225/50R17 |
Metric | 98 | Y | 1654 lbs | 50 psi | Show Specs | ||

235/35R19 |
Metric | 91 | Y | 1356 lbs | 50 psi | Show Specs | ||

235/40R18 |
Metric | 95 | Y | 1522 lbs | 50 psi | Show Specs | ||

235/45R17 |
Metric | 97 | Y | 1610 lbs | 50 psi | Show Specs | ||

235/45R18 |
Metric | 98 | Y | 1654 lbs | 50 psi | Show Specs | ||

235/50R18 |
Metric | 101 | Y | 1819 lbs | 50 psi | Show Specs | ||

245/30R20 |
Metric | 90 | Y | 1323 lbs | 50 psi | Show Specs | ||

245/35R18 |
Metric | 92 | Y | 1389 lbs | 50 psi | Show Specs | ||

245/35R19 |
Metric | 93 | Y | 1433 lbs | 50 psi | Show Specs | ||

245/35R20 |
Metric | 95 | Y | 1522 lbs | 50 psi | Show Specs | ||

245/40R17 |
Metric | 95 | Y | 1522 lbs | 50 psi | Show Specs | ||

245/40R18 |
Metric | 97 | Y | 1610 lbs | 50 psi | Show Specs | ||

245/40R19 |
Metric | 98 | Y | 1654 lbs | 50 psi | Show Specs | ||

245/40R20 |
Metric | 99 | Y | 1709 lbs | 50 psi | Show Specs | ||

245/45R17 |
Metric | 99 | Y | 1709 lbs | 50 psi | Show Specs | ||

245/45R18 |
Metric | 100 | Y | 1764 lbs | 50 psi | Show Specs | ||

245/45R19 |
Metric | 102 | Y | 1874 lbs | 51 psi | Show Specs | ||

245/45R20 |
Metric | 103 | Y | 1930 lbs | 50 psi | Show Specs | ||

255/30R19 |
Metric | 91 | Y | 1356 lbs | 50 psi | Show Specs | ||

255/30R20 |
Metric | 92 | Y | 1389 lbs | 50 psi | Show Specs | ||

255/35R18 |
Metric | 94 | Y | 1478 lbs | 50 psi | Show Specs | ||

255/35R19 |
Metric | 96 | Y | 1566 lbs | 50 psi | Show Specs | ||

255/35R20 |
Metric | 97 | Y | 1610 lbs | 50 psi | Show Specs | ||

255/40R17 |
Metric | 98 | Y | 1654 lbs | 50 psi | Show Specs | ||

255/40R18 |
Metric | 99 | Y | 1709 lbs | 50 psi | Show Specs | ||

255/40R19 |
Metric | 100 | Y | 1764 lbs | 50 psi | Show Specs | ||

255/45R18 |
Metric | 103 | Y | 1930 lbs | 50 psi | Show Specs | ||

265/35R18 |
Metric | 97 | Y | 1610 lbs | 50 psi | Show Specs | ||

265/35R19 |
Metric | 98 | Y | 1654 lbs | 50 psi | Show Specs | ||

265/40R18 |
Metric | 101 | Y | 1819 lbs | 50 psi | Show Specs | ||

275/30R19 |
Metric | 96 | Y | 1566 lbs | 50 psi | Show Specs | ||

275/35R18 |
Metric | 99 | Y | 1709 lbs | 50 psi | Show Specs | ||

275/35R19 |
Metric | 100 | Y | 1764 lbs | 50 psi | Show Specs | ||

275/35R20 |
Metric | 102 | Y | 1874 lbs | 50 psi | Show Specs | ||

275/40R17 |
Metric | 98 | Y | 1654 lbs | 51 psi | Show Specs | ||

275/40R18 |
Metric | 103 | Y | 1930 lbs | 50 psi | Show Specs | ||

275/40R19 |
Metric | 105 | Y | 2040 lbs | 50 psi | Show Specs | ||

275/40R20 |
Metric | 106 | Y | 2095 lbs | 50 psi | Show Specs | ||

285/30R18 |
Metric | 97 | Y | 1610 lbs | 50 psi | Show Specs | ||

285/30R19 |
Metric | 98 | Y | 1654 lbs | 50 psi | Show Specs | ||

285/30R20 |
Metric | 99 | Y | 1709 lbs | 50 psi | Show Specs | ||

285/35R18 |
Metric | 101 | Y | 1819 lbs | 50 psi | Show Specs | ||

285/35R19 |
Metric | 103 | Y | 1930 lbs | 50 psi | Show Specs | ||

295/30R18 |
Metric | 98 | Y | 1654 lbs | 50 psi | Show Specs | ||

295/30R19 |
Metric | 100 | Y | 1764 lbs | 50 psi | Show Specs | ||

305/30R19 |
Metric | 102 | Y | 1874 lbs | 50 psi | Show Specs |

All tire pressure data listed is for informational purposes only. TirePressure.com does not warrant or make any representations regarding the use of or the results of the use of this information. Always refer to the information on your tire sidewall for maximum tire inflation and tire load capacity.
