Goodyear Assurance CS Fuel Max Tire Pressure Chart

Goodyear Assurance CS Fuel Max

Goodyear Assurance CS Fuel Max tires come in 15 tire sizes with maximum tire load capacity of 1709 pounds to 2756 pounds and maximum tire inflation of 51 psi.

Goodyear Assurance CS Fuel Max tire load capacity and tire inflation settings may vary based on tire load index / load range. Check Goodyear Assurance CS Fuel Max tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure Goodyear Assurance CS Fuel Max tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Goodyear Assurance CS Fuel Max tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.

Select Goodyear Assurance CS Fuel Max tire size for its maximum tire inflation and load capacity.

Tire Size Max Load Capacity
(single / dual rear wheels)
Maximum Tire Pressure

225/55R19 99H

1709 lbs 51 psi

225/65R17 102H

1874 lbs 51 psi

225/70R16 103T

1929 lbs 51 psi

235/55R18 100V

1764 lbs 51 psi

235/60R17 102T

1874 lbs 51 psi

245/55R19 103T

1929 lbs 51 psi

245/70R16 107T

2149 lbs 51 psi

255/65R18 111T

2403 lbs 51 psi

255/70R16 111T

2403 lbs 51 psi

265/70R16 112T

2469 lbs 51 psi

265/70R18 116T

2756 lbs 51 psi

265/75R16 116T

2756 lbs 51 psi

P215/70R16 99T

1709 lbs 51 psi

P245/70R17 108T

2205 lbs 51 psi

P265/70R17 113T

2535 lbs 51 psi

All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
