Firestone Transforce AT Tire Pressure Chart

Firestone Transforce AT
Amazon eBay TireRack

Firestone Transforce AT tires come in 16 tire sizes with maximum tire load capacity of 1984/1819 pounds to 3638/3307 pounds and maximum tire inflation of 50 psi to 80 psi.

Firestone Transforce AT tire load capacity and tire inflation settings may vary based on tire load index / load range. Check Firestone Transforce AT tire sidewall for more information. Tire inflation and load capacity values printed on the sidewall represent the maximum air pressure Firestone Transforce AT tire can be inflated to support its maximum load capacity, and not necessarily the recommended tire pressure for your vehicle. Never overload or overinflate Firestone Transforce AT tires beyond the maximum inflation and load capacity values indicated on the tire sidewall.

Select Firestone Transforce AT tire size for its maximum tire inflation and load capacity.

Tire Size Max Load Capacity
(single / dual rear wheels)
Maximum Tire Pressure

LT215/85R16 115/112R

2679/2469 lbs 80 psi

LT225/75R16 115/112R

2679/2469 lbs 80 psi

LT225/75R17 116/113R

2756/2535 lbs 80 psi

LT235/75R15 104/101R

1984/1819 lbs 50 psi

LT235/80R17 120/117R

3086/2833 lbs 80 psi

LT235/85R16 120/116R

3086/2756 lbs 80 psi

LT245/70R17 108/104Q

2205/1984 lbs 50 psi

LT245/75R16 120/116R

3086/2756 lbs 80 psi

LT245/75R17 121/118R

3197/2910 lbs 80 psi

LT265/70R17 121/118R

3197/2910 lbs 80 psi

LT265/75R16 123/120R

3417/3086 lbs 80 psi

LT275/65R18 123/120S

3417/3086 lbs 80 psi

LT275/70R18 125/122S

3638/3307 lbs 80 psi

LT285/60R20 125/122R

3638/3307 lbs 80 psi

All listed data and/or calculations are for informational purposes only. TirePressure.com does not warrant or make any representations regarding the accuracy of or the results of the use of this information. Always refer to vehicle owner's manual for recommended tire pressure settings. Never overinflate or overload a tire beyond its maximum capabilities listed on sidewall.
